FANRYN Class B0 & B1 Rubber Insulation Pipe (Closed Cell Foam)

FANRYN Class B0 & B1 Rubber Insulation Pipe (Closed Cell Foam)
FANRYN Class B0 & B1 Rubber Insulation Pipe (Closed Cell Foam) FANRYN Class B0 & B1 Rubber Insulation Pipe (Closed Cell Foam) FANRYN Class B0 & B1 Rubber Insulation Pipe (Closed Cell Foam) FANRYN Class B0 & B1 Rubber Insulation Pipe (Closed Cell Foam) FANRYN Class B0 & B1 Rubber Insulation Pipe (Closed Cell Foam)
Informasi Dasar
Tempat asal: Cina
Nama merek: FANRYN
Kuantitas min Order: satu 40 markas
Kemasan rincian: Kantong plastik
Waktu pengiriman: 15 hari kerja
Syarat-syarat pembayaran: T/T
Harga terbaik Hubungi sekarang
Informasi Detail
Koefisien penyerapan suara: 0,85 Nama Produk: Wol Mineral Isolasi Termal
Warna: Biasanya berwarna kuning atau coklat Aplikasi: Membangun isolasi, isolasi industri
Tahan api: Tidak mudah terbakar, Kelas A1 Ketebalan: 25-100 mm
Dampak lingkungan: Dapat didaur ulang, Ramah Lingkungan Kepadatan: 40-200kg/m³
Metode instalasi: Perbaikan mekanis atau perekat Konduktivitas termal: 0,035 W/m·K
Penyerapan air: Rendah Ketahanan suhu: -269°C hingga 700°C
Bahan: Wol Mineral Kekuatan kompresi: ≥10 kPa
Ukuran: Bervariasi (misalnya, lembaran 600x1200 mm)

Deskripsi Produk

FANRYN Class B0 & B1 Rubber Insulation Pipe (Closed Cell Foam)
Overview

FANRYN rubber-plastic insulation pipe is a high-performance, flexible closed-cell foam material designed for thermal insulation in HVAC systems, plumbing, and industrial applications. Available in two fire-performance grades – Class B1 (Standard) and Class B0 (Premium) – our pipes offer excellent thermal efficiency, moisture resistance, and long-term durability. Suitable for both hot and cold piping systems, they are the ideal choice for energy-saving building projects worldwide.

Product parameter of the Class B0 rubber insulation pipe
Item Unit Specification Standard
Density Kg/m3 40~90 GB/T 6343
Temperature ℃ -50~110 GB/T 17794
Flammability —— B GB/T 8624-2006
Glass0 BS476Part 7∝Part6
Oxygen index % ≥40 GB/T 2406
SDR ≤65 GB 8627-1999
Conductivity factor
Average temperature
-20℃
0℃
40℃		 W/(m·k)

≤0.031
≤0.034
≤0.036		 GB/T 10294
Water vapor permeability Factor —— ≥1.0*104 GB/T 17146-1997
coefficient g/(m.s.pa) ≤1.96*10-11
Water absorption ratio in vacuum % ≤10 GB/T 17794-2008
Dimension stability
105±3℃,7d		 % ≤10 GB/T 8811
Crack resistance N/cm ≥2.5 GB/T 10808
Compression resilience ratio % ≥70 GB/T 6669
Anti-ozone —— Not cracking GB/T 7762
Agin resistance —— Slightly crumpling,no cracks,no pin holes,not deforming GB/T 16259
Product parameter of the Class B1 rubber insulation pipe
Item Unit Specification Standard
Density Kg/m3 ≤95 GB/T 6343
Flammability Oxygen index % ≥32 GB/T 2406
SDR —— ≤75 GB/T 8627
No less than level C when used in the construction field GB 8624-2006
Conductivity factor
Average temperature
-20℃
0℃
40℃

W/(m.k)

≤0.031
≤0.034
≤0.036		 GB/T 10294
Water vapor permeability coefficient g/(m.s.pa) ≤2.8*10-11 GB/T 17146-1997
Factor —— ≥7.0*103
Water absorption ratio in vacuum % ≤10 GB/T 17794-2008
Dimension stability
105±3℃, 7d		 % ≤10 GB/T 8811
Crack resistance N/cm ≥2.5 GB/T 10808
Compression resilience ratio
Compression ratio)50%
Compression time)72h
%		 ≥70 GB/T 6669-2001
Anti-ozone
Ozone pressure 202mpa
200h		 —— Not cracking GB/T 7762
Aging resistance
150h		 —— Slightly crumpling, no cracks, no pin holes,not deforming GB/T 16259
Temperature ℃ -40—110℃ GB/T17794
Product size of the rubber insulation pipe
Tube inner diameter (mm) 9mm thick
(1.8m/piece)		 15mm thick
(2m/piece)		 20mm thick
(2m/piece)		 25mm thick
(2m/piece)
Size
(mm*mm)		 Piece Piece/box Size
(mm*mm)		 Piece Size
(mm*mm)		 Piece Size
(mm*mm)		 Piece
6 6*9 180 180
10 10*9 140 140 10*15 80 10*20 70
13 13*9 120 100 13*15 80 13*20 50
16 16*9 100 95 16*15 60 16*20 50
19 19*9 100 80 19*15 60 19*20 40
22 22*9 100 70 22*15 60 22*20 40 22*25 30
25 25*9 80 55 25*15 60 25*20 30 25*25 25
28 28*9 60 50 28*15 50 28*20 30 28*25 25
32 32*9 60 45
34 34*15 40 34*20 30 34*25 25
35 35*9 60 40
38*9 50 30
42 42*9 50 30
43 43*9 50 30 43*15 30 43*20 25 43*25 20
48 48*9 50 28 48*15 30 48*20 25 48*25 20
54 54*9 50 25
60 60*9 50 20 60*15 30 60*20 20 60*25 15
76 76*15 25 76*20 15 76*25 15
89 89*20 15 89*25 15
108 108*20 15 108*25 10
Key Features & Benefits

  • Excellent Thermal Insulation – Low thermal conductivity (≤0.031–0.036 W/m·K) ensures maximum energy efficiency.

  • Superior Moisture Resistance – Closed-cell structure prevents water vapor penetration (µ ≥ 1.0*10⁴), ideal for chilled water pipes and condensation control.

  • Fire-Rated Safety – Class B1 meets GB/T 8624-2006; Class B0 achieves higher fire resistance (BS476 Part 7/Part 6 Glass 0).

  • Wide Temperature Range – Performs reliably from -50°C to 110°C, suitable for both freezing and hot water applications.

  • Flexible & Durable – Good pliability for easy installation; resistant to vibration, ozone, and aging.

  • Eco-Friendly & Energy-Saving – Reduces heat loss/gain, lowers carbon footprint, and complies with international environmental standards.

Packing Options:

  1. Standard: PE plastic bag

  2. Export packing: PE plastic bag + carton
    OEM packaging and custom sizes are available upon request.

Applications

Our rubber insulation pipes are widely used in:

  • HVAC Systems: Chilled water pipes, condensate pipes, hot water pipes, air ducts.

  • Plumbing: Domestic & commercial hot/cold water supply lines.

  • Industrial Piping: Insulation for cold/hot medium pipelines in processing plants.

  • Refrigeration & Air Conditioning: Condenser and evaporator line insulation.

FAQ:

Q1: How to guarantee the quality of the products?

A1: Our experienced QC team will inspect product's quality in every process

Q2: How to pack exported goods?

A2: Plastic bag (Standard Export Packing).

Q3: What is your lead time for one 40HC container order?

A3: Usual 15-20 work days after placing order.

Q4: What is your advantage on rubber insulation pipe?

A4: Special product with special specification can be made to order.

Q5: About the after-sale service, how to solve the problems occurred of your overseas customer in time?

A5: The warranty of our products is one year. If our products or packing exist quality problem, we will replace or compensate accordingly.
